Overview
The Avolites Titan Net Processor adds 16 more universes to any Titan console, with 8 DMX outputs and 2 gigabit ports in a 19 inch rack mount unit. It is configured from its front touchscreen or from a dedicated window on the console.
It suits venues, touring and installs that have outgrown the universes built into their console. A built in UPS keeps it running through short power drops.
Highlights
- Processes 16 additional universes
- 8 DMX outputs with optical and galvanic isolation
- 2 gigabit ethernet ports, front or rear
- 800 x 600 front touchscreen
- Built in UPS
- SMPTE input and MIDI in, thru and out
- 19 inch rack mount
Specifications
| Universes | 16 |
| DMX outputs | 8, optically and galvanically isolated |
| Network | 2 x gigabit, front or rear (front fitted ex works) |
| Display | 800 x 600 touch LCD |
| Other I/O | SMPTE input, MIDI in/thru/out, 2 USB |
| Power backup | UPS, 5 x 5 minute sessions |
| Format | 19 inch rack mount |
Forefront Tip
Put the Net Processor at the stage end of the network so its DMX outputs are close to the fixtures, and run a single network line back to FOH.
