Overview
The PRIME output module is the partner to PRIME inputs: 8 balanced line outputs on XLR driven by 32 bit DA converters at 96kHz. Use it where output quality really counts, such as main PA feeds, broadcast and recording sends, or high end monitor systems. It fits any DX32 slot alongside standard and AES modules.
Highlights
- 8 x XLR balanced line outputs
- 32 bit DA converters at 96kHz
- Premium path for mains, broadcast and record feeds
- Mixes with standard modules in the same DX32
Compatibility
Works with: Allen & Heath DX32 modular expander only (any slot). The DX32 then connects to dLive, Avantis, SQ/SQ+, Qu-5/6/7 (96kHz Qu only), AHM, a DX Hub or a GX4816 DX port. SQ requires firmware V1.4 or later for DX32.
Specifications
| Channels | 8 outputs |
| Connectors | XLR, balanced |
| Converters | 32 bit DA |
| Sample rate | 96kHz |
| Host | DX32 slot |
Forefront Tip
Put PRIME outs on the main left, right and sub feeds and keep a standard AOUT module for wedges and fills. That is where the extra converter quality is most noticeable.
Forefront Productions in Newcastle NSW is an authorised Allen & Heath dealer. We send orders Australia wide and are happy to check your system design before you buy.
