Overview
The CKC Lighting ZB7 BeamWash is a compact moving head that does two jobs. At its narrowest the 3.8 degree zoom throws a tight, solid beam for aerial effects, and opened out to 54 degrees it becomes an even, well blended wash for lighting the stage.
Seven 40 W Osram RGBW LEDs with individual pixel control let you run chases and effects across the front lens, and a virtual colour wheel and 2000K to 10000K colour temperature range make it easy to dial in looks quickly. At 6.5 kg its small size allows fast, smooth pan and tilt. It suits churches, schools, venues, events and hire companies who want one fixture that covers beam looks and stage wash.
Highlights
- 7 x 40 W Osram RGBW LEDs
- Motorised zoom from 3.8 to 54 degrees for beam or wash
- Individual pixel control of each LED
- Colour temperature from 2000K to 10000K, CRI 88
- Fast pan and tilt, 540 and 270 degrees
- 12, 19 and 45 channel DMX modes with RDM
- PowerCon in and out, compact 6.5 kg body
Specifications
| Light source | 7 x 40 W Osram RGBW LED |
| Zoom | 3.8 to 54 degrees, motorised |
| Colour temperature | 2000K to 10000K |
| CRI | 88 |
| Pixel control | Individual LED |
| Pan and tilt | 540 and 270 degrees |
| Strobe | 1 to 25 Hz |
| Control | DMX 12, 19 or 45 channels, RDM |
| DMX connectors | 5 pin XLR in and out |
| Power | 100 to 240 VAC, 50/60 Hz, 320 W |
| Power connectors | PowerCon in and out |
| IP rating | IP30 |
| Dimensions | 250 x 329 x 184 mm (W x H x D) |
| Weight | 6.5 kg |
Forefront Tip
Use the simple 12 channel mode when you only need wash and beam looks from a small desk, and save the 45 channel mode for when you want pixel effects across the LEDs. A pair either side of the stage, zoomed out and focused across, makes a useful colour wash that can snap to tight beams for the big moments.
