Overview
The M-DL-AES4I6O-A is the 4in 6out version of the Allen & Heath AES3 card for dLive and Avantis, with 4 stereo AES3 inputs and 6 stereo AES3 outputs on XLR connectors. It is built for balanced jobs with a few digital sources coming in, like wireless mic receivers with AES outs, and six stereo feeds to the PA.
The outputs can be set to 44.1, 48, 88.2 or 96 kHz to suit the downstream gear, and everything is patched from the I/O screen on the console.
Highlights
- 4 stereo AES3 inputs and 6 stereo AES3 outputs on XLR
- Outputs switchable 44.1, 48, 88.2 or 96 kHz
- Input SRC (32 to 192 kHz) with bypass and LED indicator
- Console can sync to the first AES input
- Fits any dLive or Avantis I/O port
Compatibility
Works with: dLive MixRacks (CDM32, CDM48, CDM64 with 1 I/O port; DM0, DM32, DM48, DM64 with 3 I/O ports), dLive surfaces (C1500, C2500, C3500 with 1 port; S3000, S5000, S7000 with 2 ports) and Avantis, Avantis Solo and the U versions (2 option slots). Requires dLive firmware V1.5 or later.
Specifications
| Format | AES3 (AES/EBU), XLR |
| Inputs | 4 stereo |
| Outputs | 6 stereo |
| Output sample rate | 44.1, 48, 88.2 or 96 kHz |
| Input SRC | 32 to 192 kHz, switchable bypass |
| Slot | dLive / Avantis I/O port |
| Firmware | dLive V1.5 or later |
Forefront Tip
Only bypass input SRC when the AES source shares the console's 96 kHz clock. Otherwise leave SRC on and the card takes care of mismatched sources.
